| Machine Components & Specifications |
| No. | Components | Qty. | Key Parameters |
| 1 | Double head manual decoiler | 1 Set | Capacity: 3 tons |
| Suitable Coil ID:508 mm |
| Suitable Coil Max OD:1000 mm |
| 2 | Guiding Unit & Leveling Unit | 1 Set | 4 Upper Rolls + 5 Lower Rolls |
| 3 | Punching Unit | 2 Set | Subject to the final design |
| 4 | Pre-Cutting Unit | 1 Set |
|
| 5 | Roll-Forming System | 1 Set | Number of forming stands: approx. 18(Subject to the final design) |
Motor Power: 3 x 7.5 kW,1 x 5.5kW
|
| Forming Speed: 18m/min(Without punching and cutting time) |
| 6 | Hydraulic Stop-and-Cut Unit | 1 Set | Cutting Blade material: Cr12MoV tool steel |
| 7 | Hydraulic Power Unit | 1 Set | Power:1 x 11kW |
| 8 | PLC Control System | 1 Set | Delta (Taiwan) / Mitsubishi(Janpan) |
| 9 | Run-Out Table(Non-powered) | 2 Pcs | Total is 6 meters |
