We can produce 1.0-4.5mm*1250/1270/1580/1830mm cut to length with/without flying cutting.
Suitable coil width | 600-1250mm/900 mm -1830 mm/800-1250mm |
Suitable coil thickness | 0.2~1.0mm/0.5-3.0mm/0.20~0.7mm |
Yield strength | 235Mpa/235-345Mpa |
The parameters of sheet coil | Max. weight 5T/10T/15T |
Inner diameter | φ508 |
Max. Width | 1250mm |
Cutting device | Max.Width is1250mm; cutter material is Cr12Mov mould steel. |
Slitting device | 5 pieces of cutter, cutter material is Cr12Mov mould steel. |
Slit strip width | width specification is adjustable but it can’t be recoiled; Min width is 80mm. |
Length tolerance | ± 1mm in 3M in length |
Slitting speed | about 15/min /about 20m/min |
Motor power | 4KW/11kw |
Hydraulic motor power | 2.2KW/5.5kw |
Cutting style | cut to length automatically |
Controller | Mitsubishi PLC |
Power source | 380V/50Hz/3phase/440V/3ph/60Hz/380V/3phase/60Hz |
Size | about 3*1.8*1.75m/about 6.9*3.7*1.6m/about 5.54*2.19*1.55M/about 8.3m*1.75*1.6m/about 6.9*3.7*1.6m/9.16*3.2*1.57m/3.4*3.5*1.55m |
Weight | about 3125kg/about 9555kg/about 8570kg/about 4535kg/about 8915kg/about 7820kg |
Flying power | 1.1kw |
Servo motor for cutting | 4kw/15kw |
Suitable raw material | cold rolled steel |
